IDC Cable

IDC cable brief

 UL2651 ribbon cable, IDC connector on both ends. IDC cable could be Molex, 3M or any other brand which is specified by customer, also proposed by us which with lower cost. IDC connector could be with or without strain relef.





IDC cable Details

Product Name: 2.54IDC Finished Gray Wire Line-12P
Gray wire spacing: 1.27mm
Gray wire specification: 2651 28AWG
Copper wire structure material: first plated and then twisted [also: first twisted and then copper plated copper-clad steel aluminum magnesium wire]
Copper core wire conductor: 7/0.12MM (7 is a 7-strand copper wire)
Outer cover color: red border gray [also available in black, yellow, and red, to be customized!]
Packaging method: 10 strips per bundle, 10 bundles per bag
Conductor diameter 0.12 ± 0.005mm
Conductor elongation rate 18 ℅ ↑
Conductor cross-sectional area 0.36mm2
Conductor twist distance 10.7mm ↓
The minimum thickness of the insulator is 0.10mm, with an average of 0.23mm
Wire diameter thickness 0.9 ± 0.05mm
Insulation elongation 100.00%
Tensile strength of insulator 1.066Kg/m ² ↑
Spark test 3.0KV/0.15SPC ↑
Withstand voltage 2KV 10mA/
Conductor resistance ≤ 237 ohms/RM ↓
Insulation resistance ≥ 100m ohms/RM ↑
Capacitor 40PF/M
Impedance of 100 ohms
Time delay 4
Working temperature: -40 ° C~+105 ° C
Insulation outer cover: environmentally friendly PVC 45P (RoHS) 8058 gray
Testing requirements:
Good appearance, plastic parts must not have injection molding defects, etc
Metal parts shall not have defects such as scratches, deformations, etc
The on-off performance meets the specified requirements





Specification

Pin QTY	Dim A	Dim B	Pin QTY	Dim A	Dim B
10	10.54	5.08	40	29.59	24.13
12	11.81	6.35	44	32.13	26.67
14	13.08	7.62	50	35.94	30.48
16	14.35	8.89	60	42.29	36.83
20	16.89	11.43	68	47.37	41.91
26	20.7	15.24	80	54.99	49.53
30	23.27	17.78	100	67.69	62.23
34	25.78	20.32



Sample picture





Harness sample picture

2.54mm cable harness

Wire type	UL2651
Cable Pitch Range	1.27mm
Connector pitch	2.54mm
Conductor range	24-30AWG
Connector Pins	6~40P,6~50P, 6~64P
Cable Color	Grey with red edge or Grey with Blue edge or black with white edge
Connector color	black, grey & red
Cable length	Customized
Applications	Computer/Desktop data transfer, Power transfer, Electronics, Communication data transfer
Certified	Hook Up wire, UL, VDE, CSA
Housing Material	PBT
Terminals	bronze and phosphor bronze
Pating	Gold-plated /nickel-plated
Rated Current	1Amp
maximum voltage	AC 500V / 1Minute
Insulation resistance	1000mΩ
Contact resistance	15mΩ
Operating Temperature	-40 ° C ~ + 105 ° C



Features:

1. Reliable Connections: IDC technology ensures a secure connection for each wire to the socket, eliminating the need for soldering or crimping and reducing failure rates.
2. High Customization: The IDC Cable Harness can be customized to meet specific customer requirements, including length, the number of ports, cable types, etc., catering to various applications.
3. High-Quality Materials: We use durable materials to manufacture the cable harness, ensuring long-term, stable performance in various environmental conditions.



1. Wide Range of Applications: Applications in the computer, communication equipment, household appliances, automotive electronics, and various other industries, addressing a wide range of connectivity needs.

2.

2.54 spec.

2.54 picture



Applications:

• Electronic device manufacturing
• Communication systems
• Data center equipment
• Computer industry
•



The IDC Cable is an efficient and reliable cable assembly solution suitable for various electronic device manufacturing needs. Its customization capabilities and ease of installation make it the preferred choice for many industries, helping to reduce costs, enhance production efficiency, and ensure exceptional connectivity performance.
