Medical Wire Harness

Connector: customer specified connector, OEM/OEM connector
Pin number: N/A
Wire: UL wire, customize wire
Water proof level: per customer requirement

Send Inquiry

Product Introduction

Medical Wire Harness is a precision-manufactured electronic wiring assembly designed specifically for medical equipment and instruments. It consists of a series of precisely connected wires, cables, connectors, and insulating materials to support the reliable operation and data transmission of medical devices.

Basic information:

Connector: customer specified connector, OEM/OEM connector

Pin number: N/A

Wire: UL wire, customize wire

Water proof level: per customer requirement

Current rating range: customize

Voltage rating: customize

Cable length: customize

Temperature rating: -40 to 105 °C

Standard: IPC-A-620/ISO9001/ISO13485

Certification: RoHS/REACH/UL/CAS/FDA

More service: OEM/ODM

More detail.

Wire Type	UL wire/ribbon cable/spring cable etc.
Wire Size	We proposed or customer specify
Wire Cores	Any
Wire material	PVC/TPU/TPE, FDA grade material is optional
Conductor	Bare Copper, Tinned Copper, Silver Plated
Rate Temperature	-20℃ to 80℃, 105℃
Certification	UL/CSA/FDA
Connector Type	We propose or customer specified connector
Protection wrap	Customer propose or we propose
Protection	Low Smoke Halogen-Free, ISO 14000
Plug Molds	We have over molding capability and connector OEM/ODM capability
Overmold material	TPU/TPE/PVC/Silicon rubber, FDA grade resin is optional
Testing	Pull test, bending test, 100% function tested, alcohol test
Application	Medical equipment, hospital
We Provide Custom Service

Applications:Medical Wire Harnesses find extensive applications in various medical equipment and settings.

More detail

1, high quality connector, medical grad. We have stable connector agent to supply us different brand connectors. Also we have capability to develop custom connector for customer.

2, high quality cable used. High flexibility, patient skin compatible, FDA material is available if customer request. Spring cable, ribbon cable and any custom construction cable is available.

3, high quality overmold manufacturing. Skin friendly material, high pull strength performance.

4, we produce the cables strictly follow IPC standard on crimping, injection, wrapping, labeling, testing, inspection, to ensure stable quality.
